FutureMatrix S5735-L8P4S-A1

Name: Buy FutureMatrix S5735-L8P4S-A1 switch online at thunder-link.com
SKU: 98011295

(0 reviews) | 4 QA

FutureMatrix S5735-L8P4S-A1 switch with 8-ports 10/100/1000BASE-T, 4-ports GE SFP, 1 AC power fixed

in stock 3-5 days lead time

PN: 98011295 Category: S5735 Series Tags: 8 Port Switch, FutureMatrix

Authorized Partner

Authorized Partner x

Authorized Partner guaranteed or sourced from officially recognized partner. Chassis and modules come with 1 year warranty.

Original New Sealed

Original New Sealed x

Original, new and sealed switch; original packaging with seal; won't unpack the product without permission (insert the power module or replace the power supply cable).

Tech Specs

Item	Specification
Dimensions without packaging (H x W x D) [mm(in.)]	Basic dimensions (excluding the parts protruding from the body): 43.6 mm x 300.0 mm x 220.0 mm (1.72 in. x 11.8 in. x 8.7 in.) Maximum dimensions (the depth is the distance from ports on the front panel to the parts protruding from the rear panel): 43.6 mm x 300.0 mm x 227.0 mm (1.72 in. x 11.8 in. x 8.94 in.)
Dimensions with packaging (H x W x D) [mm(in.)]	110.0 mm x 435.0 mm x 360.0 mm (4.33 in. x 17.13 in. x 14.17 in.)
Chassis height [U]	1 U
Weight without packaging [kg(lb)]	2.25 kg (4.96 lb)
Weight with packaging [kg(lb)]	3.17 kg (7 lb)
Typical power consumption [W]	28.4 W
Typical heat dissipation [BTU/hour]	96.9 BTU/hour
Maximum power consumption [W]	38.6 W
Maximum heat dissipation [BTU/hour]	131.71 BTU/hour
MTBF [year]	66.56 year
MTTR [hour]	2 hour
Availability	>0.99999
Noise at normal temperature (acoustic power) [dB(A)]	43 dB(A)
Number of card slots	0
Number of power slots	0
Number of fans modules	1
Redundant power supply	Not supported
Power supply mode	AC built-in
Rated input voltage [V]	AC input: 100 V AC to 240 V AC, 50/60 Hz
Input voltage range [V]	AC input: 90 V AC to 290 V AC, 45 Hz to 65 Hz
Maximum input current [A]	3 A
Memory	512 MB
Flash memory	512 MB
Console port	RJ45
Eth Management port	Not supported
USB	Not supported
RTC	Not supported
RPS input	Not supported
Service port surge protection [kV]	Common mode: ±7 kV
Power supply surge protection [kV]	±6 kV in differential mode, ±6 kV in common mode
Types of fans	Built-in
Heat dissipation	Heat dissipation with fan, intelligent fan speed adjustment
Airflow direction	Air intake from left and front, air exhaustion from right
PoE	supported
Certification	EMC certification Safety certification Manufacturing certification

Description

FutureMatrix S5735-L8P4S-A1 switch with 8-ports 10/100/1000BASE-T, 4-ports GE SFP

with 1 AC power fixed

Forwarding performance: 18 Mpps

Switching capacity: 24 Gbps/336 Gbps

PoE switch

FutureMatrix S5735-L series switches are ideal for scenarios such as enterprise campus network access and gigabit to the desktop. Built on next-generation, high-performance hardware and the Versatile Routing Platform (VRP), FutureMatrix S5735-L switches stand out with compelling features such as intelligent stack (iStack), flexible Ethernet networking, and diversified security control. They support multiple Layer 3 routing protocols and provide high performance and service processing capabilities.

Additional information

PoE Type	Non-PoE
Features	Authorized Partner, Original New Sealed
Port	1-10
Rate	GE

Q&A

Q: Does FutureMatrix S5735-L8P4S-A1 has extension slot?

A: No, it hasn’t extension slot.

Q: Does FutureMatrix S5735-L8P4S-A1 support pluggable power modules?

A: No, the switch has a built-in AC power module and does not support pluggable power modules. The built-in power module can provide 124 W PoE power, which ensures full PoE power on 8 ports in compliance with 802.3af or on 4 ports in compliance with 802.3at.

Q: What are the most compelling features for FutureMatrix S5735-L switches?

A: It supports intelligent stack (iStack), flexible Ethernet networking, and diversified security control.

Q: Can I get technical support from Thunder-link.com if we purchase FutureMatrix S5735-L8P4S-A1 from you?

A: Yes, Thunder-link.com has experienced technical team on switches, however, you may need to purchase technical support service from us as by default we only provide one year hardware warranty.
