Huawei AP3010DN-V2 access point with 1*GE port, POE
0 in stock Ready to ship
Provides 802.11n/ac wireless access networks for places with simple building structure, small size, dense users, and high capacity demands.
Provide services simultaneously on the 2.4 GHz and 5 GHz frequency bands to support more access users.
Can be flexibly deployed and work in hybrid mode (Fit AP+bridge).
Supports 2 x 2 MIMO and provides comprehensive service support capabilities.
The cost-effective AP3010DN-V2 supports 2 x 2 MIMO and provides comprehensive service support capabilities. It is deployed indoors and features high reliability, high security, simple network deployment, automatic AC discovery and configuration, and real-time management and maintenance.
Item | Description |
Interface type | 1 x 10/100/1000M port that connects to the wired Ethernet and supports PoE input. |
LED indicator | Indicates the power-on, startup, running, alarm, and fault status of the system. |
Antenna type | Built-in dual-band omnidirectional antennas |
Antenna gain | 2.4G: 4 dBi
5G: 6 dBi |
Maximum number of VAPs for each radio | 16 |
Maximum number of users | Fit AP: ≤ 128
Fat AP: ≤ 64 |
Maximum transmit power | 2.4G: 23 dBm (combined power)
5G: 23 dBm (combined power) NOTE The actual transmit power depends on local laws and regulations. |
Maximum number of non-overlapping channels | 2.4 GHz (2.412 GHz to 2.472 GHz)
5 GHz (5.18 GHz to 5.825 GHz)
NOTE The table uses the number of non-overlapping channels supported by China as an example. The number of non-overlapping channels varies in different countries. For details, see the Country Codes & Channels Compliance. |
Channel rate supported | 802.11b: 1, 2, 5.5, and 11 Mbit/s
802.11a/g: 6, 9, 12, 18, 24, 36, 48, and 54 Mbit/s 802.11n: 6.5 to 300 Mbit/s 802.11ac: 6.5 to 867 Mbit/s |
System memory | 256 MB DDR2
32 MB flash |
Power input | DC: 12 V ± 10%
PoE power supply: in compliance with IEEE 802.3af/at |
Maximum power consumption | 10.2 W
NOTE The actual maximum power consumption depends on local laws and regulations. |
Operating temperature and altitude |
-60 m to +1800 m: -10°C to +50°C 1800 m to 5000 m: Temperature decreases by 1°C every time the altitude increases 300 m. |
Storage temperature | –40°C to +70°C |
Operating humidity | 5% to 95% (non-condensing) |
IP rating | IP41 |
Atmospheric pressure | 70 kPa to 106 kPa |
Weight | 0.4 kg |
Dimensions (H x W x D) | 39.5 mm x 180 mm x 180 mm |
